| 直径: | 110mm | 重さ: | 10 kg |
|---|---|---|---|
| 材料: | 炭化鋼 | 処理型: | 鍛造 |
| 顔の形: | 平面,凸,凸 | ボタンタイプ: | 球状、放物線、弾道 |
| Diaをかんだ: | 105、110、115、120、125、130mm | エア・ホース: | 2 |
| ゲージボタン: | 6×φ14、7×φ14、8×φ14 | 前方のボタン: | 5×φ13、6×φ13、7×φ13、7×φ14 |
| パート番号: | HD45-105、HD45-110、HD45-115、HD45-120、HD45-125、HD45-130 | 岩石の硬さ: | 200-260 MPA |
| シャンクタイプ: | SD4 | ビット径(インチ): | 4 1/8インチ、4 5/16インチ、4 1/2インチ、4 3/4インチ、4 15/16インチ、5 1/8インチ |
| 挿入型: | タングステンカーバイド | ||
| ハイライト: | Carburized Steel DTH Drill Bits,Flat Face DTH Drill Bits,Convex Face DTH Drill Bits |
||
DTH hammers and bits are widely used in underground mining, quarries, hydraulic and hydro-power engineering, water well drilling, mineral exploration, anchoring hole drilling, geothermal engineering, subway excavation, and other civil engineering projects.
Key advantages include high flatness, smooth hole walls, rigid drill rod and hammer construction, independent of high axial thrust, unlimited drilling depth capability, low device costs, and easy maintenance.
| 4" Shank Bits | Bit Dia (mm) | Bit Dia (inch) | Air Hose | Gauge Buttons | Front Buttons | Part No |
|---|---|---|---|---|---|---|
| SD4 | 105 | 4 1/8" | 2 | 6×φ14 | 5×φ13 | HD45-105 |
| SD4 | 110 | 4 5/16" | 2 | 7×φ14 | 6×φ13 | HD45-110 |
| SD4 | 115 | 4 1/2" | 2 | 7×φ14 | 7×φ13 | HD45-115 |
| SD4 | 120 | 4 3/4" | 2 | 8×φ14 | 7×φ13 | HD45-120 |
| SD4 | 125 | 4 15/16" | 2 | 8×φ14 | 7×φ13 | HD45-125 |
| SD4 | 130 | 5 1/8" | 2 | 8×φ14 | 7×φ14 | HD45-130 |
Delivery options: By sea, by air, or by express shipping.
