| 重さ: | 29 kg | 材料: | 炭素鋼 |
|---|---|---|---|
| 処理型: | 鍛造 | サイズ: | 3インチ |
| 外径: | 81のmm | 長さ: | 1063 mm |
| ボタンの形状: | 弾道/半弾道/球体 | すねをかんだ: | SRC531 |
| 穴の範囲: | φ84-φ100 | 接続スレッド: | 3 分の" |
| 作業圧力: | 1.0MPa-3.0MPa | 空気消費: | 7m³/min @ 1.7 MPa |
| 空気消費: | 10m³/min @ 2.4 MPa | 空気消費: | 14m³/min @ 3.0 MPa |
| 長さ（ビット以下）: | 1069のmm | ||
| ハイライト: | SRC531 RC Hammer,3inch Reverse Circulation Hammer,81mm Down The Hole Hammer |
||
Reverse circulation drilling efficiently collects samples by transporting them through hollow pipes, preventing contamination from surface materials. This method is particularly valuable for maintaining sample integrity in mining and well drilling applications.
| Length (less bit) | 1069mm |
| Weight (less bit) | 29.0kg |
| External diameter | φ81mm |
| Bit shank | SRC531 |
| Hole range | φ84-φ100 |
| Connection thread | 3" Remet |
| Working pressure | 1.0Mpa-3.0Mpa |
| Air consumption (1.7 Mpa) | 7 m³/min |
| Air consumption (2.4 Mpa) | 10 m³/min |
| Air consumption (3.0 Mpa) | 14 m³/min |
Standard delivery time: 15-25 days. Express delivery (3-5 days) available when items are in stock.
Shipping options: By Air, By Sea, or By express.
Packaging: Ply-wooden cases with pallet.
